Shuttle 4

A reliable shuttle with space for four.

The Shuttle 4 is the ideal choice for
transporting staff and guests, as well as a
full capacity up to 1,200 lb. An optional
canopy top and an enclosed stakeside
cargo bed keep passengers and their gear
comfortably sheltered when on the move.

Stake-Side Cargo Bed

Combines functionality with a sophisticated look

Headlights (Standard)

Safely navigate in any lighting condition

Optional Windshield

Drive comfortably without exposure to the elements

Front Bumper and Brush Guard

Added vehicle protection and durability

Bench Seating

Comfortable, spacious seating for multiple passengers


Enhanced convenience and functionality
Overall Length 135.0 in (343 cm)
Overall Width 48.5 in (123 cm)
Overall Height (No Canopy) 48.6 in (123 cm) (Top of steering wheel)
Overall Height (With Canopy) 72.0 in (183 cm)
Wheel Base 93.5 in (237 cm)
Front Wheel Track 34.2 in (86.7 cm)
Rear Wheel Track 38.0 in (97 cm)
Ground Clearance @ Differential 4.3 in (11 cm)
Cargo Box Width (Inside) 42.5 in (108 cm)
Cargo Box Length (Inside) 32.0 in (80 cm)
Cargo Box Depth (Inside) 11.5 in (29 cm)
Cargo Box Capacity 9 cu ft (.25 m³)
Cargo Box Material Wood Stake Sides
Vehicle Power
Power Source 48-Volt DC
Motor Type Shunt Wound
Continuous Horsepower (kW) 2.5 hp (1.9 kW)
Intermittent Horsepower (kW) 18.1 hp (13.5 kW) @ 1900 rpm
Electrical System 48-Volt
Batteries (Qty, Type) Eight, 6V Deep Cycle
Key or Pedal Start Pedal Start
Battery Charger 48 VDC Delta Q, 120/230 VACm UL & CSA
Speed Controller 400 Amp Precision Drive System (PDS)
Drivetrain Motor Shaft Direct Drive
Transaxle Differential with Helical Gears
Gear Selection Dash-Mounted Forward-Neutral-Reverse
Rear Axle Ratio 14.7:1
Seating Capacity 4 Person
Dry Weight 720 lb (325 kg) (Without Batteries)
Curb Weight 1200 lb (545 kg)
Vehicle Load Capacity 1200 lb (545 kg)
Outside Clearance Circle 25.5 ft (7.8 m)
Intersecting Aisle Clearance N/A
Speed (Level Ground) 13 mph ± 0.5 mph (21 kph ± 0.8 kph)
Steering and Suspension
Steering Self-Compensating Rack and Pinion
Front Suspension Leaf Springs with Hydraulic Shock Absorbers
Rear Suspension Leaf Springs with Hydraulic Shock Absorbers
Service Brake Rear Wheel Mechanical Self-Adjusting Drum
Parking Brake Self-Compensating Single Point Engagement
Front Tires Links 18 x 8.50 - 8 (4 Ply Rated)
Rear Tires Links 18 x 8.50 - 8 (4 Ply Rated)
Body & Chassis
Frame Welded steel. DuraShield Powder Coat
Front Body and Finish Injection molded TPO
Rear Body and Finish Fiberglass & Gelcoat
Standard Color Patriot Blue
